Detail
Vehicle license plate enhancement
Behavior analysis: fast movement detection, line crossing detection, intrusion detection, area entry/exit detection, loitering detection
Target target detection, target capture enhancement
Computing power 1 TOPS
Resolution 4MP 2560(H)*1440(V)
Sensor photosensitive surface size 1/2.7" CMOS
Minimum illumination color: 0.005Lux (F1.2, AGC ON, 1/30 shutter), black and white: 0.0025Lux (F1.2, AGC ON, 1/30 shutter), 0Lux (infrared on)
Lens focal length 3.6mm
Lens viewing angle Horizontal: 78.8°; Vertical: 40.3° or above Angle error ±5%
Infrared light fill distance 30m
White light fill light distance 20m
Video encoding format MJPEG/H.265
Video frame rate 25fps
Audio encoding format G.711a/G.711u/G.726/OPUS/AAC
Ethernet interface supported
Number of Ethernet interfaces: 1
Ethernet interface bandwidth 1 RJ45 10M/100M adaptive Ethernet port
Power supply type DC12V, PoE (IEEE 802.3af)
Power consumption: Maximum power consumption: 12.2W, Typical power consumption: 8.2W
Working temperature -30℃~60℃
Working humidity 5%~95% (no condensation)
Protection grade IP67
Equipment anti-corrosion Class C anti-corrosion
