Image Sensor
1.0-type back-illuminated Exmor R CMOS sensor
Image Sensor (Number of Effective Pixels)
Approx. 14.2 Megapixels
Image Sensor (Total Number of Pixels)
Approx. 20.4Megapixels
Signal System
1080/59.94p,1080/59.94i,720/59,94p, 1080/50p,1080/50i, 720/50p, 1080/23.98p
Minimum Illumination (50IRE)
1.7 lux
(50IRE, F2.8, 1/30s, Max.Gain)
Horizontal Resolution
850 TV line
(in 3G-SDI output) (center)
Gain
Auto/Manual (-3dB to +33dB)
Shutter Speed
1/10000s to 1/8 (59.94/29.97)
1/10000s to 1/6 (50/25/23.98)
Exposure Control
Auto, Manual, Priority mode (shutter priority, iris priority, gain priority), Back light, Spot light
White Balance
Auto1/Auto2/One Push/Indoor/Outdoor/Manual
Tele Convert Mode
Off, 2x
*1920x1080 only
Focusing System
Auto/Manual
Horizontal Viewing Angle
Typ. 64.6° (Wide-end)
Focal Length
f=9.3 to 111.6mm
F2.8(Wide) ,F4.5(Tele)
Minimum Object Distance
1000mm(Tele)
80mm (Wide)
Pan/Tilt Angle
Pan: ±170°
Tilt: +90°/-30°
Pan/Tilt Speed
Pan:
0.3° to 60°/s *1
0.05° to 60°/s *2
0.02° to 60°/s *3
Tilt:
0.3° to 60°/s *1
0.05° to 60°/s *2
0.02° to 60°/s *3
*1 When P/T SPEED TYPE setting is NORMAL
*2 When P/T SPEED TYPE setting is Extd. RANGE (Requires firmware V2.10)
*3 When P/T SPEED TYPE setting is Extd. STEP (Requires firmware V2.10)
Pan/Tilt Operation Noise
NC30 or less*
* Sony measurement conditions
Camera Tracking Data Output
Yes
(Requires firmware V2.10)
