Detail
AXIS M3205-LVE Network Camera
Robust wide-angle surveillance in 1080p with IR
HDTV 1080p video quality
WDR and IR illumination
Wide-angle horizontal view of 100°
HDMI output and I/O connectivity
Zipstream and support for H.264/H.265
Technical specifications
Models: AXIS M3205-LVE
Camera
Image sensor CMOS
Image sensor size 1/2.9
Sensor size in megapixel 2.0
Lightfinder -
Wide dynamic range WDR
Min illumination/ light sensitivity (Color) 0.2 lux
Min illumination/ light sensitivity (B/W) 0 lux
Video
Max video resolution 1920x1080
Max frames per second 25/30
Day and Night functionality
Yes
Electronic image stabilization –
Lens
Focal length 3.1 mm
Horizontal field of view 100 °
Vertical field of view 54 °
Pan, Tilt, Zoom
Remote PTRZ –
Compression
Zipstream
Yes
H.264 High, Main
H.265
Yes
Motion JPEG
Yes
Audio
Audio Support –
Built-in microphone –
Network
PoE Class 3
Wireless –
Security
Signed firmware
Yes
Secure boot –
General
Remote focus –
Remote zoom –
Built-in IR
Yes
Local storage (memory card slot)
Yes
Operating temperature -40 to 50 °C
Outdoor Ready
Yes
Vandal rating IK10
IP rating IP66
Designed for repaint
Yes
Sustainability PVC free
Part number for ordering
NAME AXIS REGION PART NUMBER
AXIS M3205-LVE AR, AU, BR, CN, EU, JP, KR, UK, US 01517-001
AXIS M3205-LVE IN 01517-113
