M13VG2812IR Tamron DC Auto Iris CS Lens
|
M13VG2812IR
|
Imager Size
|
1/2.7
|
Mount Type
|
CS
|
Focal Length
|
2.8 - 12mm
|
Aperture Range
|
F/1.4 - 360
|
Angle of View
(Horizontal x Vertical)
|
1/2.7
|
Wide
|
107°x 79.3°
|
Tele
|
26.4°x 19.8°
|
1/3
|
Wide
|
96.8° x 71.6°
|
Tele
|
24.0° x 18.0°
|
1/4
|
Wide
|
71.6° x 53.4°
|
Tele
|
18.0° x 13.5°
|
Focusing Range
|
0.3m - ∞
|
Operation
|
Focus
|
Manual with Lock
|
Zoom
|
Manual with Lock
|
Iris
|
DC Auto Iris
|
Back Focus(in air)
|
Wide : 7.96mm (in air)
Tele : 19.39mm (in air)
|
Wave Length
|
Visible Light - Near Infrared
|
Operating Voltage
|
Open 4V
Close 0.5V
|
Weight
|
70g
|
Operating Temperature
|
-20°C - +60°C
|
Wiring Disgram
|
|
|
