M13VP288IR Tamron P-Iris Camera Lens CS
|
M13VP288IR
|
Imager Size
|
1/3 (Applicable for 1/2.7 , 1/2.8)
|
Mount Type
|
CS
|
Focal Length
|
2.8 - 8mm
|
Aperture Range
|
1.2 - Close
|
Angle of View
(Horizontal x Vertical)
|
1/3
|
Wide
|
100.1° x 72.9°
|
Tele
|
35.8° x 26.8°
|
1/4
|
Wide
|
72.9° x 53.9°
|
Tele
|
26.8° x 20.1°
|
Focusing Range
|
0.3m - ∞
|
Operation
|
Focus
|
Manual with Lock
|
Zoom
|
Manual with Lock
|
Iris
|
P-Iris
(Stepping motor switching control)
|
Filter Size
|
-
|
Back Focus(in air)
|
Wide 8.339 - Tele 14.944mm
|
Wave Length
|
Visible Light - Near Infrared
|
Operating Voltage Range
|
3.0v - 5.0v
|
Driving Curret
|
95mA : Per-phase
|
Weight
|
68g
|
Operating Temperature
|
-20°C - +60°C
|
Wiring Disgram
|
|
|
