M118VP413IR Tamron P-Iris CCTV Lens C Mount
|
M118VP413IR
|
Imager Size
|
1/1.8
|
Mount Type
|
C
|
Focal Length
|
4.0 - 13mm
|
Aperture Range
|
F/1.5 - Close
|
Angle of View
(Horizontal x Vertical)
|
1/1.8
|
Wide
|
105.4° x 77.6°
|
Tele
|
33.0° x 24.8°
|
1/2
|
Wide
|
91.7° x 67.9°
|
Tele
|
29.0° x 21.8°
|
1/3
|
Wide
|
67.9° x 50.6°
|
Tele
|
21.8° x 16.3°
|
Focusing Range
|
0.3m - ∞
|
Operation
|
Focus
|
Manual with Lock
|
Zoom
|
Manual with Lock
|
Iris
|
P-Iris
|
Excitation
|
Bi-Polar Type
|
Back Focus(in air)
|
15.235mm(in air)
|
Wave Length
|
Visible Light - Near Infrared
|
Operating Voltage Range
|
3.0 - 5.0v
|
Weight
|
167g
|
Operating Temperature
|
-20°C - +60°C
|
Wiring Disgram
|
|
|
